Technical Installation Guide for Gas Engineers: Boiler, Hot Water Cylinder, Radiators, Pipework, and Fittings

Installing a boiler, hot water cylinder, radiators, and associated pipework is a complex task that requires precision, adherence to safety regulations, and professional expertise. This guide is intended for Gas Safe registered engineers and provides a detailed, step-by-step process for installing a complete heating system, including a system or regular boiler, hot water cylinder, radiators, and necessary pipework and fittings. All installations must comply with local building regulations, Gas Safe requirements, and manufacturer specifications. Below is a comprehensive technical guide, structured for clarity and completeness.

Version 1.0 - Rough Guide



1. Pre-Installation Preparation

Before beginning the installation, thorough planning and preparation are essential to ensure safety, compliance, and efficiency.

1.1. Assess the Property

•  Evaluate Heating Requirements: Determine the heat load for the property using a heat loss calculation (e.g., based on BS EN 12831). Consider the number of radiators, bathrooms, and hot water demand. For larger homes, a regular or system boiler with a hot water cylinder is typically suitable.

•  Check Existing System: Inspect the current boiler, radiators, and pipework for compatibility with the new system. Note water pressure, radiator sizes, and flue positioning.

•  Confirm Boiler Location: Ensure the boiler location (e.g., kitchen, utility room, or airing cupboard) allows for adequate ventilation, flue installation, and access for maintenance. Check for proximity to a suitable external wall for the flue.

•  Water Supply Analysis: Assess mains water pressure and flow rate. For unvented cylinders, a minimum pressure of 1.5 bar and flow rate of 20 liters per minute are typically required. Check for hard water, which may necessitate a water softener to prevent limescale buildup.

•  Gas Supply Check: Verify the gas meter and pipework can handle the boiler’s demand (e.g., 22mm gas supply pipe for most domestic boilers). Ensure the gas supply is compliant with Gas Safe regulations.

1.2. Legal and Safety Requirements

•  Gas Safe Registration: Only Gas Safe registered engineers can install gas appliances. Ensure valid certification.

•  Building Regulations Compliance: Adhere to Part G (hot water safety), Part L (energy efficiency), and Part P (electrical safety) of the UK Building Regulations.

•  Manufacturer Specifications: Obtain the installation manuals for the boiler, cylinder, and components. Follow manufacturer guidelines for warranties and performance.

•  Permits and Notifications: Notify the local authority (e.g., via Building Control or a Competent Person Scheme) before starting work. Register the installation with Gas Safe upon completion.

1.3. Tools and Equipment

•  Pipe cutter and deburring tool

•  Pipe bending tools (for copper pipes)

•  Soldering equipment or push-fit/compression fitting tools

•  Adjustable spanners, screwdrivers, and wrenches

•  Pressure testing kit

•  Multimeter and gas leak detector

•  Power tools (drill, saw, etc.)

•  Personal protective equipment (PPE): gloves, safety glasses, etc.

1.4. Materials and Fittings

•  Boiler: System or regular boiler (e.g., 24–35 kW for medium to large homes).

•  Hot Water Cylinder: Unvented (for mains-fed systems) or vented (for gravity-fed systems), sized for household demand (e.g., 150–300 liters).

•  Radiators: Sized according to room heat loss calculations (e.g., Type 22 double-panel radiators for larger rooms).

•  Pipework: Copper pipes (15mm for radiator circuits, 22mm for flow/return, 28mm for cylinder connections) or plastic push-fit pipes where permitted (e.g., Speedfit or SharkBite).

•  Gas supply pipe (22mm copper or approved material). Always Soldered, never push fit!

•  Fittings: Compression or push-fit fittings (e.g., elbows, tees, couplers).

•  Isolation valves for each radiator and circuit.

•  Motorized zone valves (2-port or 3-port, depending on system design).

•  Pressure relief valve (PRV) for unvented cylinders (typically 3 bar).

•  Expansion vessel (sized for cylinder/system volume, e.g., 18–25 liters for unvented cylinders).

•  Temperature and pressure relief valve (TPRV) for unvented cylinders (set to 70°C).

•  Filling loop (with non-return valve, compliant with Water Regulations).

•  Pump (for fully pumped systems, typically 6m head).

•  Thermostatic radiator valves (TRVs) for each radiator.

•  Air vents (automatic or manual) for radiators and high points.

•  Inhibitor and descaler for system protection.

•  Flue Components: Flue kit (horizontal or vertical), terminal guard (if required), and flue pipe extensions.

•  Controls: Programmable room thermostat, cylinder thermostat, and two-channel programmer for independent heating and hot water control.

2. System Design and Layout

Design the system to ensure efficient operation and compliance with regulations. A typical setup for a system or regular boiler with a hot water cylinder includes:

•  Fully Pumped System: Both heating and hot water circuits are pumped, with motorized valves for zone control.

•  Y-Plan or S-Plan Configuration:

•  Y-Plan: Uses a 3-port motorized valve to divert hot water between heating and hot water circuits.

•  S-Plan: Uses separate 2-port motorized valves for heating and hot water, offering better control for larger systems.

•  Pipework Layout: Two-pipe system (flow and return) for radiators to ensure even heating.

2.1. Pipework Design

•  Flow and Return Pipes: Use 22mm pipes for main flow/return from the boiler to the distribution point, then 15mm for individual radiator branches.

•  Hot Water Cylinder Connections: 22mm or 28mm pipes for primary flow/return to the cylinder’s heat exchanger (indirect cylinders).

•  Cold Feed (Vented Systems): 22mm pipe from the header tank to the cylinder.

•  Unvented Systems: 22mm mains cold feed to the cylinder, with a balanced cold water supply for outlets.

•  Gas Supply: 22mm copper pipe from the meter to the boiler, ensuring no joints in inaccessible areas.

2.2. Radiator Placement

•  Position radiators under windows or on external walls to counter heat loss.

•  Ensure adequate clearance for air circulation (e.g., 100mm above and below).

•  Calculate radiator sizes using heat loss figures (e.g., 1.5–2 kW for a typical bedroom).

3. Installation Process

Follow these steps carefully, ensuring all work is performed by a Gas Safe registered engineer.

Step 1: Remove the Old System (if applicable)

1.  Turn Off Utilities:

•  Shut off the gas supply at the meter.

•  Isolate the water supply to the existing boiler and cylinder.

•  Turn off the electrical supply to the boiler and controls.

2.  Drain the System:

•  Connect a hose to the lowest drain cock and drain the system into a suitable container or external drain.

•  Open radiator bleed valves to release trapped air and aid draining.

3.  Remove Old Components:

•  Disconnect and remove the old boiler, cylinder, and associated pipework.

•  Cap the gas supply temporarily to prevent leaks.

•  Remove old radiators if they are being replaced.

Step 2: Install the Boiler

1.  Mount the Boiler:

•  Fix the boiler mounting bracket to a solid wall, ensuring it is level and can support the boiler’s weight.

•  Hang the boiler according to the manufacturer’s instructions, ensuring clearance for maintenance and flue installation.

2.  Install the Flue:

•  Cut a hole in the external wall for a horizontal flue or route a vertical flue through the roof.

•  Install the flue kit, ensuring a minimum 2° upward slope toward the terminal to allow condensate drainage.

•  Fit a terminal guard if the flue terminates less than 2m above ground level.

3.  Connect Gas Supply:

•  Run a 22mm copper pipe from the gas meter to the boiler’s gas inlet.

•  Use compression fittings or soldered joints, ensuring no leaks (test with a gas leak detector).

•  Install an isolation valve near the boiler for future maintenance.

4.  Connect Flow and Return Pipes:

•  Connect 22mm flow and return pipes to the boiler’s outlets, using compression or push-fit fittings.

•  Install the system pump (if not integrated into the boiler) on the flow or return pipe, following manufacturer guidance.

5.  Electrical Connections:

•  Connect the boiler to a dedicated fused spur (3A fuse, typically).

•  Wire the pump, motorized valves, and controls to the boiler’s wiring center, following the manufacturer’s wiring diagram.

Step 3: Install the Hot Water Cylinder

1.  Position the Cylinder:

•  Place the cylinder in a suitable location (e.g., airing cupboard or utility room) with adequate access for maintenance.

•  For vented cylinders, ensure the header tank is above the cylinder to provide gravity-fed pressure.

2.  Install Pipework:

•  Unvented Cylinder:

•  Connect a 22mm mains cold feed to the cylinder’s inlet, including an isolation valve and non-return valve.

•  Install the pressure relief valve (PRV) and temperature/pressure relief valve (TPRV) as per Part G regulations.

•  Fit an expansion vessel to accommodate water expansion (size per manufacturer’s specification).

•  Run a discharge pipe from the PRV/TPRV to a safe external termination point (e.g., tundish to drain).

•  Vented Cylinder:

•  Connect a 22mm cold feed from the header tank to the cylinder.

•  Install a vent pipe (22mm) from the cylinder to discharge over the header tank.

•  Connect 22mm primary flow/return pipes from the boiler to the cylinder’s heat exchanger (indirect cylinders).

3.  Install Safety Devices:

•  Fit a 2-port motorized zone valve on the primary flow to the cylinder, controlled by the cylinder thermostat.

•  Install a cylinder thermostat to regulate water temperature (typically set to 60°C to prevent legionella).

Step 4: Install Radiators

1.  Mount Radiators:

•  Fix radiator brackets to walls, ensuring they are level and secure.

•  Hang radiators, ensuring clearance for air circulation.

2.  Connect Pipework:

•  Run 15mm flow and return pipes from the main 22mm circuit to each radiator.

•  Use compression or push-fit fittings to connect pipes to radiator valves.

•  Install thermostatic radiator valves (TRVs) on the flow side of each radiator for temperature control.

•  Fit lockshield valves on the return side to balance the system.

3.  Install Air Vents:

•  Fit manual or automatic air vents at the highest point of each radiator to remove trapped air.

Step 5: Install System Controls

1.  Programmer and Thermostats:

•  Install a two-channel programmer to control heating and hot water independently.

•  Fit a room thermostat in a central location (e.g., living room), away from heat sources or drafts.

•  Connect the cylinder thermostat to the motorized valve controlling the hot water circuit.

2.  Motorized Valves:

•  For an S-Plan system, install two 2-port valves: one for the heating circuit and one for the hot water circuit.

•  For a Y-Plan system, install a 3-port valve to divert flow between heating and hot water.

3.  Wiring:

•  Wire all controls to the boiler’s wiring center, ensuring compliance with Part P regulations.

•  Test electrical connections with a multimeter to confirm correct operation.

Step 6: Fill and Test the System

1.  Fill the System:

•  For unvented systems, use a filling loop to pressurize the system to 1–1.5 bar (check manufacturer’s specification).

•  For vented systems, fill via the header tank, ensuring no airlocks.

•  Add a corrosion inhibitor to the system water to protect against limescale and corrosion.

2.  Bleed the System:

•  Open radiator bleed valves to remove air, starting with the lowest radiators and working upward.

•  Check for leaks at all fittings and joints.

3.  Pressure Test:

•  Pressurize the system to 1.5 times the operating pressure (e.g., 2.25 bar for a 1.5 bar system) and check for pressure drops over 10 minutes.

•  Use a gas leak detector to confirm no gas leaks at the boiler and gas pipe joints.

Step 7: Commission the System

1.  Start the Boiler:

•  Turn on the gas and electrical supplies.

•  Follow the manufacturer’s commissioning procedure, including setting the gas valve and checking combustion efficiency with a flue gas analyzer.

2.  Balance the System:

•  Adjust lockshield valves on radiators to ensure even heat distribution (typically, radiators furthest from the boiler require more flow).

•  Check that all radiators heat evenly and reach the desired temperature.

3.  Test Hot Water:

•  Turn on hot water taps to confirm the cylinder delivers water at 55–60°C.

•  Verify the cylinder thermostat and zone valve operate correctly.

4.  Check Controls:

•  Test the programmer, room thermostat, and TRVs to ensure they control the system as expected.

•  Confirm the PRV/TPRV operates if the cylinder overheats (unvented systems).

Step 8: Final Checks and Handover

1.  Inspect the Installation:

•  Verify all pipework is secure and insulated where necessary (e.g., external pipes).

•  Ensure the flue is sealed and correctly installed.

•  Check for compliance with Gas Safe and Building Regulations.

2.  Customer Handover:

•  Explain the boiler and control operation to the homeowner.

•  Provide the manufacturer’s manuals and Gas Safe certificate.

•  Advise on regular maintenance (e.g., annual servicing by a Gas Safe engineer).

3.  Notify Authorities:

•  Register the installation with Gas Safe and notify Building Control (or use a Competent Person Scheme).

4. Safety Considerations

•  Carbon Monoxide: Install a carbon monoxide detector near the boiler and ensure proper flue installation to prevent CO leaks.

•  Electrical Safety: All electrical work must comply with Part P regulations. Use a qualified electrician if necessary.

•  Pressure Safety: Ensure PRV/TPRV and expansion vessels are correctly installed to prevent over-pressurization.

•  Legionella Prevention: Set the cylinder thermostat to 60°C to minimize the risk of legionella bacteria.

•  Gas Safety: Test all gas connections with a leak detector and ensure the gas supply complies with BS 6891.

5. Common Issues and Troubleshooting

•  Airlocks: Bleed radiators and high points to remove air. Use an automatic air vent if persistent.

•  Uneven Heating: Balance the system by adjusting lockshield valves.

•  Leaks: Tighten fittings or replace faulty components. Use PTFE tape for threaded joints if necessary.

•  Low Pressure: Check for leaks or top up the system via the filling loop (unvented systems).

•  Noisy System: Limescale or sludge buildup may require a power flush.

6. Maintenance Recommendations

•  Annual Servicing: Arrange for a Gas Safe engineer to service the boiler and cylinder annually.

•  System Flushing: Perform a power flush every 5–7 years or if sludge is detected.

•  Inhibitor Checks: Test and top up the corrosion inhibitor annually.

•  Radiator Bleeding: Bleed radiators annually or if they feel cold at the top.

7. Additional Notes

•  Push-Fit vs. Copper: Push-fit fittings (e.g., Speedfit, SharkBite) can simplify installation in tight spaces but must be rated for high temperatures and pressures. Copper is traditional and durable but requires soldering skills.

•  Unvented vs. Vented Cylinders: Unvented cylinders are more common in modern installations due to higher pressure and no need for a header tank, but they require additional safety devices. Vented systems are simpler but less efficient.

•  System Upgrades: Consider installing smart controls (e.g., Nest or Hive) for improved efficiency and user convenience.

This guide assumes a fully pumped system with an unvented hot water cylinder and a two-pipe radiator layout, which is common in modern UK homes. Always consult the manufacturer’s instructions and local regulations, as requirements may vary. For further guidance, refer to the Gas Safe Register website (www.gassaferegister.co.uk) or the manufacturer’s technical support.
